HMTH-1300 is a manual lathe that has been trusted and loved for a long time based on precision and best performance.
HMTH-1300 provides a product line-up and optional specifications that can respond to various customer needs, and maximizes user convenience for easy and convenient use.
Item | HMTH-1300 | |
---|---|---|
Travel | ||
X-axis Stroke | mm | 950 |
Y-axis Stroke | mm | 300 |
Z-axis Stroke | mm | 450 |
Max. Distance between table surface to Spindle Nose |
mm | 수직 Spindle : 120 ~ 570 Horizontal Spindle : 30 ~ 480 |
Table | ||
Table Size | mm | 1,300 x 280 |
Max. Loading Capacity | kgf | 250 |
T-Slot (Slot W x P / No. of slots) |
mm | 16 x 60 / 3ea |
Spindle | ||
Spindle Speed | rpm | 75 ~ 3,600 / 16 step [50Hz : 60 ~ 3,000 / 16 Step] |
Spindle Motor (2p / 4p) |
kW | 2 / 1 |
Type of Spindle Taper Hole | N.T | 40 |
퀼 이송거리 | mm | 140 |
Quill Auto Feed | mm/rev | 0.035, 0.07, 0.14 |
Rotation degree | deg | 90˚ |
Y-Axis Stroke (Overarm) | mm | 555 |
Overarm Swivel | deg | 180˚ |
Horizontal Spindle | ||
Spindle Speed | rpm | 95 ~ 1,400 / 9 Step |
Horizontal Spindle Motor | kW | 3.7 |
Type of Spindle Taper Hole | N.T | 40 |
Feedrate | ||
X, Y Axis Rapid Feed | mm/min | 3,000 [50Hz : 2,500] |
X, Y Axis Auto Feed | mm/min | 15~720 / 12 Step [50Hz : 13 ~ 600 / 12 step] |
Motor | ||
Feed-Axis (X / Y / Z) |
kW | 0.75 / 0.75 / 0.75 |
Lubrication Motor (Slide) |
W | 36 |
Coolant Motor | W | 100 |
Power Source | ||
Electric Power Supply | kVA | 8 |
Power Specification | - | 220V, 60Hz / 380V, 60Hz |
Tank Capacity | ||
Coolant | ℓ | 35 |
Machine Size | ||
Height | mm | 2,370 |
Floor Space (L x W) |
mm | 2,450 x 1,800 |
Weight | Kgf | 2,040 |
